규
격
(Inch) |
길이
(Length mm) |
치수
(mm) |
사용하중
(Ton) |
무게
(kg) |
| A |
B |
C |
D |
| EYE |
JAW |
HOOK |
EYE |
JAW |
HOOK |
All
Type |
All
Type |
EYE
JAW |
HOOK |
EYE |
JAW |
HOOK |
| 3/8x6 |
443.8 |
410 |
- |
291.3 |
257.6 |
- |
152.4 |
180.8 |
0.54 |
- |
0.3 |
0.4 |
- |
| 1/2x6 |
510 |
470 |
- |
332.2 |
292.1 |
- |
152.4 |
190.5 |
1 |
- |
0.5 |
0.7 |
- |
| 1/2x9 |
662.4 |
622.3 |
- |
408.4 |
368.3 |
- |
228.6 |
266.7 |
1 |
- |
0.7 |
0.8 |
- |
| 1/2x12 |
814.8 |
774.7 |
- |
484.6 |
444.5 |
- |
304.8 |
342.9 |
1 |
- |
1 |
1.1 |
- |
| 5/8x6 |
557 |
509.3 |
520.7 |
372.9 |
325.1 |
336.6 |
152.4 |
200.2 |
1.59 |
1.02 |
1.3 |
1.2 |
1.2 |
| 5/8x9 |
709.4 |
661.7 |
673.1 |
449.1 |
401.3 |
412.8 |
228.6 |
276.4 |
1.59 |
1.02 |
1.5 |
1.6 |
1.5 |
| 5/8x12 |
861.8 |
814.1 |
825.5 |
525.3 |
477.5 |
489 |
304.8 |
352.6 |
1.59 |
1.02 |
1.6 |
1.8 |
1.6 |
| 3/4x6 |
606.5 |
546.1 |
568.5 |
416.1 |
355.6 |
378 |
152.4 |
209.6 |
2.36 |
1.36 |
1.7 |
1.9 |
1.8 |
| 3/4x9 |
759 |
698.5 |
720.9 |
492.3 |
431.8 |
454.2 |
228.6 |
285.8 |
2.36 |
1.36 |
2.1 |
2.5 |
2.4 |
| 3/4x12 |
911.4 |
850.9 |
873.3 |
568.5 |
508 |
530.4 |
304.8 |
362 |
2.36 |
1.36 |
2.5 |
2.9 |
2.5 |
| 3/4x18 |
1216.1 |
1155.7 |
1178.1 |
720.9 |
660.4 |
682.8 |
457.2 |
514.4 |
2.36 |
1.36 |
3.3 |
3.7 |
3.7 |
| 7/8x12 |
941.6 |
891.8 |
914.4 |
592.3 |
542.5 |
565.2 |
304.8 |
371.3 |
3.27 |
1.82 |
3.3 |
3.7 |
3.7 |
| 7/8x18 |
1246.4 |
1196.6 |
1219.2 |
744.7 |
694.9 |
717.6 |
457.2 |
523.7 |
3.27 |
1.82 |
4.5 |
4.9 |
4.5 |
| 1x6 |
710.4 |
627.9 |
651 |
507.2 |
424.7 |
447.8 |
152.4 |
228.6 |
4.54 |
2.27 |
4.1 |
4.6 |
4.2 |
| 1x12 |
1015.2 |
932.7 |
955.8 |
659.6 |
577.1 |
600.2 |
304.8 |
381 |
4.54 |
2.27 |
5.2 |
5.7 |
5.4 |
| 1x18 |
1320 |
1237.5 |
1280.6 |
812 |
729.5 |
752.6 |
457.2 |
533.4 |
4.54 |
2.27 |
6.4 |
6.9 |
6.4 |
| 1x24 |
1624.8 |
1542.3 |
1565.4 |
964.4 |
881.9 |
905 |
609.6 |
685.8 |
4.54 |
2.27 |
7.8 |
8.2 |
7.8 |
| 1
1/4x12 |
1087.4 |
1011.9 |
1027.2 |
719.1 |
643.6 |
658.9 |
304.6 |
384 |
6.9 |
2.95 |
8.6 |
9.3 |
9.3 |
| 1
1/4x18 |
1392.2 |
1316.7 |
1332 |
817.5 |
796 |
811.3 |
457.2 |
536.4 |
6.9 |
2.95 |
10.4 |
11.2 |
10.4 |
| 1
1/4x24 |
1697 |
1621.5 |
1637.8 |
1023.9 |
948.4 |
963.7 |
609.6 |
688.8 |
6.9 |
2.95 |
12.3 |
12.8 |
12.3 |
| 1
1/2x12 |
1155.7 |
1054.1 |
- |
774.7 |
673.1 |
- |
304.8 |
400.1 |
9.72 |
- |
12.5 |
13.9 |
- |
| 1
1/2x18 |
1460.5 |
1358.9 |
- |
927.1 |
825.5 |
- |
457.2 |
552.5 |
9.72 |
- |
14.1 |
16.7 |
- |
| 1
1/2x24 |
1765.3 |
1663.7 |
- |
1079.5 |
977.9 |
- |
609.6 |
704.9 |
9.72 |
- |
17 |
18.5 |
- |
| 1
3/4x18 |
1457.5 |
1355.9 |
- |
1000.3 |
898.7 |
- |
457.2 |
568.5 |
12.71 |
- |
23.8 |
24.5 |
- |
| 1
3/4x24 |
1762.2 |
1660.7 |
- |
1152.7 |
1051.1 |
- |
609.6 |
720.9 |
12.71 |
- |
26.3 |
28.8 |
- |
| 2x24 |
1922.5 |
1766.3 |
- |
1312.9 |
1156.7 |
- |
609.6 |
736.6 |
16.8 |
- |
38.7 |
42.8 |
- |
| 2
1/2x24 |
1997 |
1853.7 |
- |
1387.3 |
1244.1 |
- |
609.6 |
788.9 |
27.24 |
- |
65.5 |
74.9 |
- |
| 2
3/4x24 |
2057.4 |
1898.7 |
- |
1447.8 |
1289.1 |
- |
609.6 |
788.9 |
34.05 |
- |
88.1 |
89.9 |
- |
|
| |
|
| |
| |
| |
|
|
|
|
|
